In-line/Sidewall Duct Fan Series New Product

PRF Model

Model Features

  • Duct lips sized for easy fit with standard PVC couplings typically used in radon mitigation applications
  • Fully sealed, high-quality plastic housing
  • Large, easily accessible, watertight electrical box for unobstructed wiring process
  • Easily mount on duct pipe or use heavy-duty metal mounting bracket (sold separately)
  • Significantly less expensive than comparable alternatives
  • Thermal overload protection
  • HVI Certified Performance
  • cETLus certified

HVI Certified Performance   cETLus certified

Model Overview

PRF fans are specifically designed for radon mitigation. The fully-sealed plastic fans feature backward inclined centrifugal blower/motors capable of handling up to 1" of static pressure. The PRF series feature duct lips sized for an easy fit with standard PVC couplings typically used in radon mitigation applications. Additionally, the PRF is engineered with large, easily accessible, watertight electrical boxes for unobstructed wiring process.

5-year fan housing warranty, 5-year motor warranty

Size Duct Dia. Max. CFM Nom. RPM Voltage / Frequency Max. Watts Current Max. SP Max. Temp. of Transported Air Avg. Ship Weight
100 4" 169 3080 120V / 60Hz 92W 0.77A 1" 140°F 6.6 lbs
150 6" 321 2890 120V / 60Hz 136W 1.15A 1" 140°F 8.2 lbs
Dimensional Drawing for the PRF Models
Size A B C
100 4" or 5" 10-9/16" 10-3/4"
150 6" 9-1/2" 12"

Note: Additional accessories are available for certain products. Contact your JencoFan Representative for more information about these accessories.

Standard Accessories

MD Motorized Backdraft Damper SubmittalIOM
PR-M PRF U-tube Manometer & Label Kit
PF-BRKT Metal mounting bracket for PRF fan

PRF Brochure
Radon Mitigation Pamphlet
Instruction and Operation Manual
